Product Details
＋
Omron M12 x 1 Magnetic Proximity Sensor - Barrel, 7 mm Detection, IP67, Cable Terminal E2EQ-X7D212-M1TGJ-T 0.3M
Specifications:
- Sensor Technology Inductive
- Body Style Barrel
- Thread Size M12 x 1
- Detection Range 7 mm
- Terminal Type Cable
- Supply Voltage 10 â 30 V dc
- Series E2E-NEXT
- Length 47.1mm
- Width 21mm
- Maximum DC Voltage 30V
- Mounting Type Flush Mount
- IP Rating IP67
- Switching Current 100 mA
- Housing Material Brass
- Shielding Shielded
- Minimum Operating Temperature -25°C
- Short Circuit Overload Protection Yes
- Maximum Operating Temperature 70°C
- Standards Met CE Certificate, CSA C22.2 No.14-13, UL 508, UL Certified
- Maximum Switching Frequency 250Hz
